Comewill, as a professional high quality Instrument Room Dehumidifier 30W manufacturer, you can rest assured to buy Instrument Room Dehumidifier 30W from our factory and we will offer you after-sale service and timely delivery. It cuts down both relative and absolute humidity by reducing air moisture content, with almost no temperature rise. No more issues from internal temperature differences. This directly lowers accident risks, and unlike heat-based solutions, it won’t speed up the aging of cabinet parts or the cabinet itself.
We’ve swapped passive dew prevention for active dew removal. This stops all the common cabinet problems: equipment aging, weaker insulation, secondary terminal breakdown, mold on internal materials, and steel structure rust. Your power grid stays safe and stable, long-term.
Welcome (Wenzhou) Electric Co., Ltd. — our smart dehumidification device packs a punch with these practical features, built for real-world electrical cabinet use. Bulk orders, sample requests, competitive pricing — we’ve got all your sourcing needs covered.
1.Compact and lightweight, so it takes up barely any space. One person can install Instrument Room Dehumidifier 30W in minutes, no special tools or complicated brackets needed.
2.Switch between auto and manual dehumidification whenever you want. You can also tweak the temp and humidity trigger points to match your exact cabinet environment.
3.Double the moisture control power: active condensation in the dehumidification duct, plus heated exhaust air to cut down humidity even more. This gets every last bit of damp out of sealed electrical cabinets, no corners left wet.
4.High-precision temp and humidity sensors run 24/7, non-stop. The second readings go over your preset limits, the condensation system kicks in automatically — no need for manual checks.
5.Your custom temp and humidity settings stay saved, even if the power cuts out or you turn the device off and on again. No more reconfiguring everything from scratch every time.
6.Clear fault display lets you spot problems right away. You can identify the exact issue in seconds, minimizing downtime and keeping your system running smoothly.
7.We use dedicated moisture-resistant components throughout the device. Instrument Room Dehumidifier 30W works reliably even in super humid environments, no performance drops or early failures.
8.Advanced shielding isolation technology is built right in, meeting GB/T17626-2008 Level 3 standards. It runs perfectly stable in strong electromagnetic fields — ideal for power grid and industrial setups.
9.Two flexible drainage options to choose from: connect the built-in tube to drain water directly outside the cabinet, or use a portable storage bag for collection if piping isn’t convenient. Either way, your cabinet stays dry and clean.
| PARAMETER INFORMATION | |
| Power input | AC/DC85-265V,50Hz |
| Working power supply | AC/DC110V~220V 50/60Hz |
| Display method | Double row three digit digital display |
| Input specifications | 1 channel temperature and humidity input module |
| Measuring Range | Temperature:-20℃~99℃;humidity:20%RH~99%RH |
| Basic error | Temperature:±0.5℃(-20°℃~99°℃),Humidity:±5%RH(20%RH~99%RH) |
| Resolution | Temperature:1℃,humidity:1%RH |
| control mode | Positional control |
| Output specifications | 1 relay output,250VAC/3A or 30VDC/3A |
| Rated power | 65W |
| Humidity start value | 65%RH |
| Humidity stop value | 55%RH |
| Sensor type | Built-in |
| External temperature load | Optional configuration |
| Communication RS485 | Optional configuration |
| Recommended dehumidification space | 0.8-1.0m³ |
| Drainage method | Silicone hose drainage |
| work environment | Non corrosive environments with a temperature of-10~80℃and a humidity of ≤85%RH |
| Shell material | Engineering plastic |
| External dimensions(mm) | Length 138×width 100xthckness 63 |
| Installation method | DIN-Rail Mounting |
